| Chipset |
Intel H310 |
| Supported CPU |
Supports 8th Generation Intel® Core™ Processors (Socket 1151)
- Supports CPU up to 95W
- 5 Power Phase design
- Supports Intel® Turbo Boost 2.0 Technology |
| Supported Memory |
DDR4 2666 / 2400 / 2133 non-ECC, un-buffered memory
Dual Channel DDR4 Memory Technology |
| Onboard Audio |
7.1 CH HD Audio (Realtek 887/897 Audio Codec)
Supports Surge Protection
1 x Front Panel Audio Connector
HD Audio Jacks: Line in / Front Speaker / Microphone |
| Onboard LAN |
Intel GbE LAN chip (1 Gbit/100 Mbit) |
| BIOS |
128Mb AMI UEFI Legal BIOS with multilingual GUI support
ACPI 6.0 Compliant wake up events
SMBIOS 2.7 Support
DRAM, PCH 1.05V Voltage Multi-adjustment |
| PCI |
1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)
1 x PCI Express 3.0 x1 Slot |
| M.2 Socket |
N/A |
| Memory Type |
Type
DDR4
Slots
2 x DIMM Slots
Maximum Memory
64GB |
| Graphics |
1 x D-Sub
* Graphics specifications may vary between CPU types.
** Intel 11th & 10th Gen processors support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz. Please refer to www.intel.com for any update.
*** Only Intel 11th Gen processors support HDMI 2.0 with max. resolution of 4K@60Hz, others will only support HDMI 1.4 with max. resolution of 4K@30Hz. Please refer to www.intel.com for any updates.
Expansion Slots Intel 11th & 10th Gen Processors |
| HDMI |
HDMI
1 x HDMI Port (HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz)
D-Sub (s)
1 x D-Sub Port
DVI-D (s)
1 x DVI-D Port |
| USB (s) |
1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection)
1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection) |
| Supported Storage |
4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 15), NCQ, AHCI and Hot Plug |
| Internal I/O Ports |
Fan and cooling related
1 x 4-pin CPU Fan header
1 x 4-pin Chassis Fan header
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
Storage related
2x M.2 slots (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports
Miscellaneous
1 x Clear CMOS header
1 x Front Panel Audio header (AAFP)
1 x Speaker header
1 x 10-1 pin System Panel header |
| TPM (Trusted Platform Module) |
N/A |
