| Chipset |
Intel H510 Express Chipset
|
| Supported CPU |
Supports 10th Gen Intel Core Processors, 11th Gen Intel Core Processors, Pentium Gold and Celeron Processors1 |
| Supported Memory |
Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel CPU (by JEDEC & POR)
Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel CPU (by JEDEC & POR)
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel Extreme Memory Profile (XMP) |
| Onboard Audio |
Realtek ALC887 codec
High Definition Audio
2/4/5.1/7.1-channel
To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
Support for S/PDIF Out |
| Onboard LAN |
Intel GbE LAN chip (1 Gbit/100 Mbit) |
| BIOS |
1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| PCI |
1x PCIe x16 slot (From CPU)
- Support up to PCIe 4.0 for 11th Gen Intel CPU
- Support up to PCIe 3.0 for 10th Gen Intel CPU
1x PCIe 3.0 x1 slot (From PCH) |
| M.2 Socket |
1x M.2 slot with E key for WiFi module only(M2_2) |
| Memory Type |
DDR4 Dual channel memory architecture
2 x DDR4 DIMM
Up to 64 GB (32 GB single DIMM capacity) of system memory |
| Graphics |
1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz
1x VGA port, supports a maximum resolution of 2048x1536 60Hz, 1920x1200 60Hz
1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz |
| HDMI |
1 x HDMI
|
| USB (s) |
- 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector)
- 6x USB 2.0 ports (4 Type-A ports on the back panel(hub-GL850G), 2 ports available through the internal USB 2.0 connector) |
| Supported Storage |
4x SATA 6Gb/s ports (From H510 Chipset)
1x M.2 slot (Key M)
- M2_1 slot (From H510 Chipset)
- Supports up to PCIe 3.0 x4
- Supports SATA 6Gb/s1
- Supports 2242/ 2260/ 2280 storage devices |
| Internal I/O Ports |
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x M.2 Socket 3 connector
4 x SATA 6Gb/s connectors
1 x CPU fan header
2 x system fan headers
1 x RGB LED strip header
1 x front panel header
1 x front panel audio header
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
1 x serial port header
1 x Clear CMOS jumper |
| TPM (Trusted Platform Module) |
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) |
| Others |
Support for APP Center
@BIOS
Ambient LED
EasyTune
Fast Boot
Game Boost
ON/OFF Charge
Smart Backup
System Information Viewer
Support for Q-Flash
Support for Xpress Install |
