Supported CPU : Support for Intel Core i7 processors/ Intel Core i5 processors/ Intel Core i3 processors/ Intel Pentium processors/ Intel Celeron processors in the LGA1150 package
Chipset : Intel H81 Express Chipset
Type : Dual Channel Architecture
Slots : 2 x DDR3 DIMM sockets
Supported Memory : Support for DDR3 1600/1333 MHz memory modules
-Support for non-ECC memory modules
-Support for Extreme Memory Profile (XMP) memory modules
Maximum Mamory : 16 GB
Graphics : 1 x D-Sub port, supporting a maximum resolution of 1920×1200
Max Shared Memory : 1 GB
Connector & Ports
USB (s) :
-2 x USB 3.0/2.0 ports
-2 x USB 2.0/1.1 ports
LAN Port (s) :
-Realtek GbE LAN chip (10/100/1000 Mbit)
-1 x RJ-45 port
Supported Storage :
-2 x SATA 6Gb/s connectors (SATA3 0~SATA3 1)
-2 x SATA 3Gb/s connectors (SATA2 2~SATA2 3)
Audio
Realtek ALC887 codec
High Definition Audio
2/4/5.1/7.1-channel
Internal I/O Ports
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
2 x SATA 6Gb/s connectors
2 x SATA 3Gb/s connectors
1 x CPU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
1 x speaker header
2 x USB 2.0/1.1 headers
1 x chassis intrusion header
1 x Clear CMOS jumper
D-Sub (s) : 1 x D-Sub port
